A8104-215-1720

DUAL 21.5″ Ultra-Rugged Sunlight Readable (16:9) 1080P LCDs Integrated into a Pelican 1720 Protector Long Case

The challenge most have is the need to be able to leave the screen in the case while closed and ported in any orientation without the screen coming loose, allowing for reliable stationary positioning during use, while at the same time keeping it removable for repair/replacement. With the robust design and state-of-the-art features of these industrial-grade LCD monitors, it meets the demands of today’s harsh environment applications including ROV/Drones, First Responders, Military, Field Analysis, Offshore, Robotics, etc. While these display monitor/cases offer excellent mobility, we ensure that it can withstand the demanding conditions commonly encountered in these applications.

Technical Specifications

Model
A8104-215-1720
Display Size
Dual 21.5" 1080P LCDs
Display Type
Long-Life Industrial Grade LCD
Backlight Technology

Solid State, Long-Life LED – CLICK HERE for more information

Optical Films Enhancements

Boosts efficiency of the backlight’s light utilization and minimizes the surface reflection of ambient light. The result is a transmissive enhancement that features higher contrast and a wider range of colors, even in bright outdoor light, than traditional reflective LCDs.

Brightness
1200 nits (cd/m2) each LCD
Dimming Capabilities
Front Sealed Manual Full-Range Dimming Turn Potentiometer
Contrast Ratio
4300:1
Aspect Ratio
16:9
Resolution
1920 x 1080 (1080p) – True High-Definition
Colors Supported
16.7M (8-bit/color)
Viewing Angles
- 89 ~ 89 horizontal, - 89° ~ 89° vertical
Video Inputs
DVI, HDMI, DisplayPort, Composite
User Controls
Optional Front User Membrane Keypad
Protective Window

Protective Window

Power Types
90 VAC to 264 VAC; 12V DC; 24V DC; 9 to 36V DC; or 20 to 53V DC
Front Bezel
High Grade 6061T Aluminum, Electrochemical Anodized for added Corrosion Resistance, Black Textured Finish per Military Standards FED-STD-595
Panel Mounting
IP65 at LCD front bezel
Overall Dimensions
44.48 x 16.07 x 6.25 in (112.98 x 40.82 x 15.88 cm)
Weight
Configuration Dependent
Sealability
Extreme Anti-Shock and Anti-Vibration Design
Sunlight Readability
The latest optical technology for high ambient light conditions
Warranty Period
1 Year
Sunlight Readability
The latest optical technology for high ambient light conditions
Operating Temperature Range
-20°C to +70°C (158°F)
Storage Temperature
-20°C to +70°C (158°F)
Humidity
5% to 95% RH (non-condensing)
Fasteners
Vibration-proof, self-locking, fastener system
EMI
FCC Class B pursuant to Part 15 of the FCC Rules
Agency Compliance
CE
Altitude
Operating 0 to 10,000 ft. / Storage 0 to 40,000 ft.
RoHS Compliant
Yes
Rating
NEMA 4 / IP65
Case Properties
  • Watertight, crushproof, and dustproof Polypropylene enclosure
  • IP67 case when latch closed
  • Open cell core with solid wall design – strong, light weight
  • Fold down Comfortable rubber over-molded handle
  • Retractable extension trolley handle
  • Strong polyurethane wheels with stainless steel bearings and nylon hubs
  • Easy open double-throw ABS latches
  • Stainless steel hardware and padlock protectors
  • Automatic pressure equalization valve – balances interior pressure, keeps water out
  • Purge Vent Material: 3 Micron Hydrophobic Non-Woven
  • Polymer O-ring seal (70 Shore Nitrile)
  • Stainless Steel Pins
  • MIL STD 810F case when latch closed
  • MIL STD 810G Fungus Test case when latch closed
Dimensions
  • Exterior
  • Inches: 44.48 x 16.07 x 6.25″ (112.98 x 40.82 x 15.88 cm)
  • Interior
  • Inches: 41.80 x 13.58 x 5.33″ (106.17 x 34.49 x 13.54 cm)
  • Bottom Depth: 4.37″ (11.1 cm)
Model
A8104-215-1720
Display Size
Dual 21.5" 1080P LCDs
Display Type
Long-Life Industrial Grade LCD
Backlight Technology

Solid State, Long-Life LED – CLICK HERE for more information

Optical Films Enhancements

Boosts efficiency of the backlight’s light utilization and minimizes the surface reflection of ambient light. The result is a transmissive enhancement that features higher contrast and a wider range of colors, even in bright outdoor light, than traditional reflective LCDs.

Brightness
1200 nits (cd/m2) each LCD
Dimming Capabilities
Front Sealed Manual Full-Range Dimming Turn Potentiometer
Contrast Ratio
4300:1
Aspect Ratio
16:9
Resolution
1920 x 1080 (1080p) – True High-Definition
Colors Supported
16.7M (8-bit/color)
Viewing Angles
- 89 ~ 89 horizontal, - 89° ~ 89° vertical
Video Inputs
DVI, HDMI, DisplayPort, Composite
User Controls
Optional Front User Membrane Keypad
Protective Window

Protective Window

Power Types
90 VAC to 264 VAC; 12V DC; 24V DC; 9 to 36V DC; or 20 to 53V DC
Front Bezel
High Grade 6061T Aluminum, Electrochemical Anodized for added Corrosion Resistance, Black Textured Finish per Military Standards FED-STD-595
Panel Mounting
IP65 at LCD front bezel
Overall Dimensions
44.48 x 16.07 x 6.25 in (112.98 x 40.82 x 15.88 cm)
Weight
Configuration Dependent
Sealability
Extreme Anti-Shock and Anti-Vibration Design
Sunlight Readability
The latest optical technology for high ambient light conditions
Warranty Period
1 Year
Sunlight Readability
The latest optical technology for high ambient light conditions
Operating Temperature Range
-20°C to +70°C (158°F)
Storage Temperature
-20°C to +70°C (158°F)
Humidity
5% to 95% RH (non-condensing)
Fasteners
Vibration-proof, self-locking, fastener system
EMI
FCC Class B pursuant to Part 15 of the FCC Rules
Agency Compliance
CE
Altitude
Operating 0 to 10,000 ft. / Storage 0 to 40,000 ft.
RoHS Compliant
Yes
Rating
NEMA 4 / IP65

Additional Add-On Options

Touch Screen Technology:

Multi-Touch Up to 10-Point PCAP

Or can be fitted with an Optical Grade Protective Impact Window





Various Color Cases Available:  Black (standard) or Desert Tan







Video Input Options: DVI, HD15 (VGA), DisplayPort, HDMI, Composite, S-Video, and/or NTSC/PAL

Can be setup for Hot-Toggle Selection Between Multiple Video Inputs

Extended Operational Temperature Ranges

Power Type Choices: 90 VAC to 264 VAC; 12V DC; 24V DC; 9 to 36V DC; or 20 to 53V DC

Custom Boot-Up Splash Screen with YOUR Logo

Private Labeling Services

Customization Services

Custom Video Modes
